母线槽系统不仅可以与配电系统的其他元件结合使用，而且还可以与电力的产生、传输和转换以及用电设备的控制联系在一起。
The busduct system can not only be used in combination with other components of the power distribution system, but also be connected with the generation, transmission and conversion of power and the control of electrical equipment.
规划基于输入功率(例如，馈电变压器的额定电流和短路电流)和母线槽系统的安装容量以及以下数据进行：-允许的电压降-要求的防护等级-电源系统配置-权衡诸如电缆系统或母线槽系统的供电概念-短路强度-过载和短路保护，著名母线槽品牌。
Planning is based on input power (such as rated current and short circuit current of feeder transformer) and installed capacity of busduct system as well as the following data: - allowable voltage drop - required protection level - power system configuration - weighing power supply concepts such as cable system or busduct system - short circuit strength - overload and short circuit protection.
根据项目条件和不同的制造商，可以选择不同的母线槽系统：
According to project conditions and different manufacturers, different busduct systems can be selected:
01三明治设计，尺寸紧凑。
Sandwich design, compact size.
02通风母排设计，散热性好。
The ventilation busduct design has good heat dissipation.
03如果对严酷环境的防护等级有最高要求，则采用浇注母线槽系统。
If the highest level of protection is required for severe environment, the pouring busduct system shall be adopted.
各种系统可以包括不同数量的导体。PE导体可以实现为单独的母线或外壳。N导体可以是单个导体，也可以是双片的。
Various systems can include different numbers of conductors. PE conductors can be implemented as separate busducts or enclosures. The N conductor can be a single conductor or a double piece.
电气设备室和干线竖井越小，电气负载的功率密度和要传输的功率越大，空间问题就变得越重要。由于电缆散发到环境中的热量，必须在它们之间留有空隙。母线槽系统中散热被集成，从而无需间隙。母线槽系统还可以通过直角弯头，改变方向来节省空间，著名母线槽品牌。
The smaller the electrical equipment room and main shaft, the greater the power density of the electrical load and the power to be transmitted, and the more important the spatial issue becomes. Due to the heat emitted by cables into the environment, gaps must be left between them. Heat dissipation in the dusduct system is integrated so that no gaps are required. The busduct system can also save space by changing direction through right angle elbow.
美嘉科技 (镇江) 有限公司为一家台资独资企业，是一家专业生产母线槽及配套产品的电气制造公司，其母线槽产品以节能、环保、安全的硫化绝缘为核心技术，服务于 更高端的半导体行业。美嘉科技不仅拥有 CCC 认证、ISO 系列认证，还拥有国际权威 KEMA KEUR 认证，为确保客户使用放心，美嘉科技对其产品的部分核心技术和材料做了专项国际认证，我们期待与您的合作!
Mega Technology (Zhenjiang) Co., Ltd., a Taiwan funded sole proprietorship, is an electrical manufacturing company specializing in the production of busduct and supporting products. Its busduct products take energy-saving, environmental protection and safe vulcanized insulation as the core technology, serving the more high-end semiconductor industry. Mega Technology not only has CCC certification and ISO series certification, but also has international authoritative KEMA KEUR certification. To ensure customers can use it with confidence, Mega Technology has made special international certifications for some of its core technologies and materials. We look forward to cooperating with you!
